    Single Stage Compressors

    Enquiry
    Model Motor No. of Cylinder. Piston Displacement Maximum Pressure Air Receiver (itrs.)
      hp kw RPM CFM Ipm PSIG kg/cm2
    AC 5 S1 1.00 3.75 1 3.76 106 125 8..78 60
    AC 5 S2 2.00 1.50 2 7.46 210 125 8..78 100
    AC 535 3.00 2.24 2 14.85 420 80 5.62 150
    AC 535 5.00 3.70 2 20.00 566 80 5.62 150
    AC 544 7.50 5.60 2 34.60 980 80 5.62 225
    AC 555 10.00 7.46 2 52.80 1495 80 5.62 225
    AC 507S2 12.50 9.33 2 88.00 1491 40 2.81 300
    AC 515S2 20.00 14.92 3 148.50 4204 40 2.81 500
